Automatic Polyurethane Sandwich Panel Machine Pneumatic Piston Driving

Name: Automatic Polyurethane Sandwich Panel Machine Pneumatic Piston Driving
Brand: Lv changda
Price: 1 USD

China Automatic Polyurethane Sandwich Panel Machine Pneumatic Piston Driving wholesale

Brand Name : Lv changda

Model Number : MZ2017093008

Certification : ISO CE SGS

Place of Origin : Jiangsu, China

MOQ : 1 set

Price : negotiable

Payment Terms : L/C, T/T, Western Union, MoneyGram, D/A, D/P

Supply Ability : 10 Sets/month

Delivery Time : 60 days after receiving 30% deposit

Packaging Details : Nude package in 40' container

After-sales Service Provided : Engineers available to service machinery overseas

Color : Optional

Use : Sandwich panel

Name : Sandwich pu foaming machine

Product thickness : 50-150mm

Material of main shaft : 40Cr

control system : PLC control

Uncoiling speed : 0-12m/min

Hydraulic system pressure : 6.3MPa

Warranty : 2 years

Contact Now

High efficiency sandwich pu foaming machine

Working procedure

Decoiler – roll forming—Polyurethane Foaming and Injecting—Heating-- Compressing—Cutting--– product to run out table

Brief introduction

This production line is a kind of specialized equipment for producing sandwich panel with the middle layer of anti-combustion polyurethane and with aluminum foil as the top and bottom face layer.s The sandwich panel is 10-40mm in thickness, 1250mm in width, length determined by the customer. The sandwich panel is mainly used as keeping warm for wall and roof (or ceiling). Different insulating panels with other soft facing layers could also be produced on the line.

Main technical datas

Re-coiler

Name	Discription
Dimensions	1700mm1000mm800mm
Width of feeding	Max 1500mm
Maximum loading coil weight	5000kg
Inter diameter	450-510mm
Mode of expand &fight	Inner expand &fight by Hydraulic
Way of feeding	Manual

Main forming system

Name	Discription
PU foam thickness	10-40mm
Standard Sandwich Panel Size	Max1250mm x 4000mm( W*L)
Linear Speed of production	2-5 m/min
Maximum sheet embossing peed	10 m/min
Reciprocating times of injection head	<60( per minute)
Production type	Continuous production with PLC controlling
Composite structure	Position fixed by double rubber tracker
Foaming system	Totally automatically continuous foaming, quantity of foaming could be stepless adjustable
Main Power of production	≥ 35KW
Cutting	Pneumatic piston driving, non-stop cutting via sliding table
Electronic controlling system	Full-frequency PLC controlling system
Raw Material	0.4-0.8mm
Coil Width	1250mm or customized
Working Speed	0-10 m/min
Roller Material	Superior alloy steel forged parts
Roller Size	￠320mmx 1250 (Coil width)
Main Motor Power	11 KW

Machine pictures

Automatic Polyurethane Sandwich Panel Machine Pneumatic Piston Driving
